| 產品特性： |
|
|
|
|
|
|
| 濕度 ： |
|
10%RH ~ 95%RH |
|
|
|
|
| 溫度 ： |
|
-20°C ~ +65.0°C (-4°F ~ +149°F) |
|
|
| 不適指標： |
過冷/過熱, 過乾/過濕 |
|
|
|
| |
|
|
|
|
|
|
|
| 產品規格明細： |
|
|
|
|
|
|
| 溫度測量範圍： |
-20°C ~ +65.0°C (-4°F ~ +149°F) |
|
|
| 準確度： |
±1°C (0°C ~ +40°C) |
|
|
|
| 解析度： |
0.1°C (0.1℉) |
|
|
|
|
| 取樣時間： |
可由程式設定(2, 5, 10, 20, 30… 秒) |
|
|
| 濕度測量範圍： |
10%RH ~ 95%RH |
|
|
|
|
| 準確度： |
30%RH ~ 80%RH (±3%RH + 1 digital at +25°C) |
|
| |
|
Others within 5%RH |
|
|
|
| 解析度： |
1%RH |
|
|
|
|
|
| 取樣時間： |
可由程式設定(2, 5, 10, 20, 30… 秒) |
|
|
| LCD螢幕尺寸： |
95mm X 27mm |
|
|
|
|
| 電源： |
|
4號電池1.5V(AAA)x2或USB供電(<2.8V低電源指示) |
|
| 電腦介面： |
USB 2.0 相容介面 虛擬序列埠(RS-232模式) |
|
| 操作環境： |
溫度0°C ~ +65°C 濕度 10%RH ~ 95%RH |
|
| 儲存環境： |
溫度0°C ~ +40°C 濕度 <90%RH |
|
|
| 軟體功能： |
顯示、儲存、記錄、設定、圖表… |
|
|
| 內附USB連接線及軟體光碟 |
|
|
|
|
|
| 專利申請中 |
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
| FEATURES: |
|
|
|
|
|
|
| Humidity: |
|
10%RH ~ 95%RH |
|
|
|
| Temperature: |
|
-20°C ~ +65.0°C (-4°F ~ +149°F) |
|
| Uncomfortable Indicator |
COLD/HOT, DRY/WET |
|
|
| SPECIFICATIONS: |
|
|
|
|
|
|
| Temperature : |
Measuring Range -20°C ~ +65.0°C (-4°F ~ +149°F) |
| |
|
Accuracy ±1°C (0°C ~ +40°C) |
|
|
|
| |
|
Resolution 0.1°C (0.1°F) |
|
|
|
| |
|
Sampling Time program setting (2, 5, 10, 20, 30, …Sec) |
| Humidity : |
Measuring Range 10%RH ~ 95%RH |
|
|
| |
|
Accuracy 30%RH ~ 80 %RH (±3%RH + 1 digital at +25°C) Others within 5%RH |
| |
|
Resolution 1%RH |
|
|
|
|
| |
|
Sampling Time program setting (2, 5, 10, 20, 30, …Sec) |
| LCD : |
|
95mm X 27mm |
|
|
|
|
| Power : |
|
UM-4 1.5V (AAA) x 2 or USB power (< 2.8V Low Battery Indicator) |
| PC Interface : |
USB 2.0 compatible virtual com port (RS232 mode) |
| Operation Condition : |
Temperature 0 ~ +65°C, Humidity 10%RH ~ 95%RH |
| Storage Condition : |
Recommend 0 ~ +40°C, < 90%RH |
|
|
| Software Function : |
Display、Storage、Recorder、Setting、Chart.... |
|
| USB cable & software included |
|
|
|
|
|
| Patent Pending |
|
|
|
|
|
|
產品編號：
