| SENSORS(COMBINED) |
Temperature : pt 100Ω DIN, IEC 751
Humidity : macro-molecule humidity sencor |
| MEASUREMENT RANGE |
Temperature : -20~+80℃
Humidity : 0~100%RH |
| ACCURACY(TAMB=25℃) |
Temperature : ±0.4℃
Humidity : ±2.5%RH(30~90%RH) |
| OUTPUT SIGNALS |
Temperature : 4~20mA two-wire
Humidity : 4~20mA two-wire
zero and span adujstable
※option : voltage output
|
| PERMISSIBLE LOAD RESISTANCE |
Current output type : less than 600Ω (at 24V power supply) |
| POWER SUPPLY |
DC 9~40V , approx. 60mA |
| HOUSING |
plastic mounting case (water-resistant) |
| WEIGHT
AMBIENT TEMPERATURE
|
Approx. 220g |
| -20~+85%(transducer) |
